Description
Engineered with modern materials, advanced design, and precision manufacturing, the Turbosmart turbocharger series delivers unmatched performance for motorsport and high-performance enthusiasts alike. These turbos are designed to be smaller, lighter, and faster, setting a new benchmark in transient response and overall efficiency.
What’s Included
Every Turbosmart turbocharger comes with:
-
Weld flanges
-
V-band clamps
-
Gaskets
-
Oil feed & drain fittings
Everything needed for a seamless installation is included in the box.
TS-1 Series Overview
-
Cooling: Oil-cooled
-
Housing: Lightweight, investment-cast turbine housing
-
Core: Proprietary bearing and main shaft combo for superior transient response
-
Performance: High power at low shaft speeds, excellent under heavy load
Built from the ground up with a system-level approach, Turbosmart turbos reduce backpressure and increase flow, delivering power with better response than conventional units.
Available Configurations
-
TS-1: Oil-cooled
-
TS-2: Oil & water-cooled
-
Mounting Options: V-Band, T3, and T4 flange
-
Rotation: Reverse rotation (selected sizes)
-
Wastegate: Internal or external
-
A/R Options: Multiple available
Key Features
-
Unrivaled transient response
-
Aggressive 7+7 2618 aluminum splitter wheels
-
Lightweight 310S stainless steel turbine housings
-
Lightweight aluminum compressor covers
-
CFD-optimized housings for perfect flow and A/R
-
713C Inconel turbine wheel for extreme EGTs
-
VSR speed balanced
-
Proprietary dual ceramic bearing system
-
Integrated iron backplate on center housing
Specifications
-
Compressor Inlet: 4″ / 101.6mm
-
Compressor Inducer: 71mm
-
Turbine Inlet: T4
-
Turbine Exducer: 70mm
-
Turbine A/R: 0.96
-
Turbine Outlet: V-Band (3.00″)
-
Weight: 6.86kg / 15.1 lbs
-
Horsepower Rating: 875–1010 HP
