Blue Sea Systems Circuit Breaker 187 Panel Mount 50A

Description

Description

• Combines switching and circuit protection into a single device*.
• Clear, single lever operation.
• “Trip Free” design cannot be held “ON” during fault current condition.
• Waterproof.
• Recessed mounting holes for clean appearance.
• Large Clearance around terminal studs accept heavy gauge wire lugs.
• Robust 5/16 M8 terminals provide high torque connections.
• Large lever with vertical/horizontal orientation provides indication of trip status.
• Ignition protected – Safe for installation aboard gasoline powered boats.
• * Do not use as a switch where high inrush currents are expected.

Features

Specification

Maximum Voltage	:	48V DC
Interrupt Capacity	:	5000A @ 14VDC 3000A @ 28VDC 1500A @ 48VDC
Mounting	:	Panel Mount
Weight	:	0.23Kg
Warranty	:	1 Year
Circuit Breaker Type	:	Thermally responsive Bi-metal blade
Maximum Operating Temperature	:	85������C
Minimum Operating Temperature	:	-40������C

Compatibility

Please make sure your current battery has the matching required specification to ensure a like for like replacement.

Compatibility Check

Before sending out your ordered part(s), we perform a compatibility check to guarantee that they will fit your vehicle. This verification can be done by using your registration number (UK) or the last 7 digits of your VIN. Simply enter your car information before proceeding to checkout.

Part Number

BLUE SEA-7039B-BSS

More Information

Manufactured by

BLUE SEA
