For The Competitive Off-Road
The superior design of the BILSTEIN M 9200 (Coilover) is comprised of aerospace-class materials and engineered to the tightest tolerances. Available in multiple lengths and valvings for a wide range of race applications.
Increased Travel
Multiple stroke lengths available ranging from 8″ to 16″.
Larger Piston Diameter
The 46mm and 60mm large bore hard anodized aluminum piston combined with a 22mm piston rod offer a greater range of damping control, provides brute tensile strength and reduces internal gas force ramp-up for a smoother ride and exceptional long-term durability.
Threaded Body for Quick Adjustments
Threaded body with dual-rate coilover hardware allows users to make quick spring and preload changes, and adjust the transition between a dual and single rate. The softer dual rate will provide a smoother ride over choppy terrain and the stiffer single rate will provide increased compression control.
Features
- Available in 46mm and 60mm monotubes
- Threaded body with dual-rate coilover hardware
- Multiple stroke lengths available ranging from 8” to 16”
- Case hardened, centerless ground 22mm piston rod
- Machined billet aluminum components
- 5/8” uniball mounts with 1/2” step spacers
- 60mm remote reservoir
- 46mm shock uses a 2.5” ID Coilover Spring
- 60mm shock uses a 3.0” ID Coilover Spring
- 3 stage high-temp seal
- Red synthetic high-temp racing oil
- Zinc plated
- Multiple valvings available
- Owner rebuildable
- Made in the USA
- 46mm coil carrier (non reservoir) and 60mm coilover with Reservoir available
Characteristics
| Fitting Position | : | Rear Axle |
| Length [mm] | : | 533 mm |
| Parameter | : | 260/120 |
| Shock Absorber Design | : | Absorber does not carry a spring |
| Shock Absorber Mounting Type | : | Bottom eye, Top pin |
| Shock Absorber System | : | Monotube |
| Shock Absorber Type | : | Gas Pressure |
Compatibility
- B3
- B3 (E30) (09.87 – 06.92)
- 2.7
- 3 SERIES
- 3 (E30) (09.82 – 03.92)
- 315 / 316 / 316 i / 318 i / 318 is / 320 i / 320 is / 323 i / 325 i / 325 e 2.7 / M3 2.3 / M3 EVO I 2.3 / M3 EVO II 2.5
- 3 Compact (E36) (01.94 – 08.00)
- 316 i / 316 g / 318 ti / 323 ti / 318 tds
Compatibility Check
Before sending out your ordered part(s), we perform a compatibility check to guarantee that they will fit your vehicle. This verification can be done by using your registration number (UK) or the last 7 digits of your VIN. Kindly provide your car information before proceeding to checkout.
Part Number
BILSTEIN-24-233637
More Information
Manufactured by
Bilstein
EAN
4025258737061
UPC
651860738239
